BT(stepping motor) auto iris, High performance megapixel lense,60mmF0.95
Experience the bright colour image in Extreme low light level conditions in the world today.
| 1¡±F0.8/60mm CS | 2/3" | ||
| Focal Length | f=60mm | ||
| Max Diameter Ratio | F=1:0.8 | ||
| Picture Size | 9.6*12.8 | 6.6*8.8 | |
| Angle | Ver. | 9.6¡ã | 6.6¡ã |
| Hor. | 12.8¡ã | 8.8¡ã | |
| Dia | 16¡ã | 11¡ã | |
| Distortion(TV) | -0.15% | -0.15% | |
| Minimum Focus Distance | 3m | ||
| Flange Back | 12.5mm in air | ||
| Back Focus | 20mm in air | ||
| Filter Screw Size | M77*0.75 | ||
| Front/Rear Effective Dia. | Front Diameter70.0mm£»Rear Diameter25.8mm | ||
| Mount | CS-Mount | ||
| Exit Pupl | Minus 278.1mm | ||
| Temperature Range | Minus 10-50 degree | ||
| Storage Temperature Range | Minus 20-60 degree | ||
| Resolution Center/Corner | Center120TVL/mm Corner 100TVL/mm | ||
| Weight | g | ||
